Spun bonded filter cartridges are made up of 100% polypropylene fibers. The fibers have been carefully spun together to form a true gradient density from outer to inner surface. Filter cartridges are available with core & without core version. The superior structure remains integral even under severe operating conditions and there is no media migration. Polypropylene fibers are blown continuously on central molded core, without any binders, resins or lubricants.
Download Brochure
Unfiltered fluid passes through depth filter matrix and enables the progressive retention of finer particles, which
provides high efficiency, high dirt retention & long filter life. Fluid flows from outside to inside through filter media. Particulates are held securely in the filter matrix and clean fluid flows to the downstream side of cartridge.
| Free of surfactants, binders and adhesives |
| Excellent flow with low pressure drop |
| High dirt holding capacity |
| High strength & pressure resistance |
| 100 % Polypropylene for wide chemical compatibility |
| One piece construction up to 1016 mm & more |
| Nominal & absolute filtration rating |
| NSF42 and FDA CFR title 21 Certified cartridges are available |
| Sizes | 10”, 20”, 30”, 40”, 50”, 60” Long |
|---|---|
| Micron Rating | 1, 5, 10, 25, 50, 75, 100 |
| Outer Diameter | 64 mm (2.5”), 114mm (4.5”), 6”, 8″ |
| Inner Diameter | 25mm, 28 mm, 48 mm |
| Double Open Type (DOE Type) |
| Code 7S (226 ‘O’ Ring Design/Bayonet) |
| Code 7F (226 ‘O’ Ring Design/Flat) |
| Code 3S (222 ‘O’ Ring Design/Bayonet) |
| Code 3F (222 ‘O’ Ring Design/Flat) |
Spun bonded filter cartridges are made up of 100% polypropylene.
| Food & Beverages | Bottled water, Flavors, Polishing Lines |
|---|---|
| Pharmaceuticals | Base product clarifications, Membrane prefilter |
| Fine Chemicals | Solvents, Process Streams, Water Purification |
| Magnetic coating | Dispersions, Coating Lines, Solvents |
| Petrochemicals | Water flood, Comletion Fluids, Amines |
| Cosmetics | Alcohols, Essential oils , Water lines |
| Water Treatment | Membrane Protection, Resin Trap |
| Metal Finishing | Plating solution, paint and resin products, Wash |
| Electronics | Electroplating, Etching, Image development |
